Custom Heat Exchangers
To Protect Your Electrical and Electronic Equipment
A reliable cooling system is critical in today’s electrical and electronic systems. With the amount of heat generated from various power components, too much heat in an enclosure can cause damage to sensitive equipment, potentially causing failure.
A heat exchanger is a device used to transfer thermal energy between two or more fluids, which are at different temperatures. In most cases, the fluids can exchange heat without direct contact. The most basic function is to remove heat from a specific location by turning the heat into a fluid. This fluid takes the heat and passes it to a second fluid without mixing or coming into direct contact. As the heat passes to the second fluid, the original fluid will now cool down as it travels back to the original point. The process then starts over again.
Air to Air or Liquid to Air.
It is important to point out that the fluids can be a gas, such as air, or can be a liquid such as water or dielectric fluids and they don’t have to be consistent.
Special Environmental Needs Can Include:
Nickel Aluminium Cupronickel
Paint Coatings High Cosmetic Requirements
Fans and Pumps
Fans and/or pumps are often used to keep these gases or liquid moving, as fans move gases and pumps moves liquid. Some applications can also benefit from increased heat transfers by adding heat pipes.
Designs Can Include Various:
-Zipper Fin. -Folded Fin. -Heat Pipes. -Dip Brazing. -Fin Patterns Nickel Plating --Bend Densities. - Vacuum Brazing -Pipe Connections. -Soldering / Welding - ---Friction Stir Welding. -Mounting Structures
Baknor’s extensive knowledge of cooling systems weighs various trade-offs and factors such as functionality, manufacturability volume, mass, cost, packaging, efficiency, and the reliability and safety of heat dissipation components. Let us customize a heat exchanger to meet your demanding heat transfer requirements.
Custom Air-To-Air Heat Exchanger
Air to air heat exchangers can be used to keep electrical components cool. They transfer thermal energy between two separate air streams. They allow two air streams to come into close contact with each other - close enough that the energy in one can be transferred to the other, but not so close that contaminants are also exchanged.
Using Heat Pipe Technology
Today’s heat exchangers often use heat pipe technology to move heat from inside an enclosure to the outside air. With very low energy consumption there are no moving parts, which increases the overall reliability and reduces maintenance needs. The heat pipe transfers heat by using a phase-changing fluid that absorbs heat from the enclosure as a liquid, converts it to a vapor, and then releases the heat to the outside air. As it releases the heat, the liquid cools and moves back to its original starting point. This will continue to circulate while moving heat out of the enclosure.
Closed Air Loop
An air-to-air heat exchanger is a closed loop system. This ensures that any contaminants, dust and dirt are kept out of the enclosure. This is a major benefit over ventilation fans. Air-to-air heat exchangers provide moderate to good cooling performance
Benefits of Heat Pipe Heat Exchangers
-Minimal power. - No fan controls
-No filter required. -Less maintenance -Low noise.
- No thermostats required. -Transfers heat in one direction
- Lower complexity. -Lower cost. -- Smaller. -More efficient
BRING US YOUR TOUGHEST THERMAL APPLICATION CHALLENGE
Use Our Design Services or Send Us Your CAD Drawings
Start the conversation with our thermal design solution professionals, by using our thermal design check list, to analyze and solve your thermal challenges.
